| Notommata allantois, dorsoventral view. This image shows the conspicuous double bladder (asterisks), which is characteristic for this species. (3) |
| |
 |
| Notommata allantois: while swimming N. allantois shows its retractile "auricles", (yellow triangles). N. allantois is characterised by a round tail (Ta). (1) |
| |
 |
| Notommata allantois: ventral side showing two rectractor muscles (white triangles) and the buccal field which surrounds the mouth (yellow triangle). (1) |
| |
|
|
|
| Notommata allantois: The triangles in the right image point to the openings of the ducts of the retrocerebral organ (RCO). Similar structures have also been found in other Notommata-species, like for example Notommata copeus.(2) |
| |
 |
| Notommata allantois : mastax; with slight asymmertric trophi, green triangles pointing at the pleural rod.s Yellow triangles pointing at the gastric glands. (1) |
| |
|
| Notommata allantois, specimen with retracted auricles while creeping; ventral view. (3) |
| |
 |
| Notommata allantois, swimming specimen from (5), dorsoventral view. |
| |
|
| Notommata allantois, two aspects of the virgate trophi ; upper ileft: dorsal view, focal plane on the rami. Upper right: ventral view. (5) Lower image: trophi of specimen from (2) |
| |
| |
| |
|
|
|
|
| |
|
Location(1): Simmelried near Konstanz, BW, Germany, pond II |
 |
| |
| Habitat (1): between Sphagnum |
| |
| Date : 02.08.2009 (1) |
| |
|
|
|
|
|
| |
| |
| Location: Simmelried/ Bodensee (1); nature reserve "Heiliges Meer", Germany, (2). Gieringer Moor, Tirol, Austria (3) |
| Habitat : Sphagnum (1); Sphagnum pond + Utricularia (2); Sphagnum (3) |
| Datum: 2.7.2012 (2); 7.07.2014 (3) |
|
|
